BPC® Titan
BPC® Titan is a versitile gas volume and flow meter for high gas flow measurements.
- Gas volume and flow meter
- 1.5 L measurement resolution
- Aurora™ software included
High-volume gas flow measurement for microbial fermentation
The BPC® Titan is a cutting-edge analytical instrument designed for online monitoring of fermentation processes that demand high gas throughput or involve significant gas production. With a broad linear detection range up to 360 L/h and a measurement resolution of 1.5 L, it provides a user-friendly solution with instant feedback and real-time data monitoring.
The robust design of the BPC Titan ensures precise and accurate gas measurements across large flow rate intervals, making it ideal for both research and industrial applications. This instrument is an enhanced version of the BPC Go, offering the same advanced features and extended measurement range to take gas volume and flow measurement to the next level.
Equipped with
1.5 L resolution
For high gas flow measurement needs
Detection range up to
360 L/h
Ideal for monitoring large bioreactors
Software
Aurora™ included
Set up, monitor and export data in the browser
Features
Automated testing
Measure gas volume and flow automatically, with minimal intervention required during a test.
Browser based software
Included Aurora™ software lets users set up, monitor and review experiments remotely and locally in the browser.
Automated compensation
Real time pressure, temperature and moisture compensation helps normalise gas volume and flow data to standard conditions.
Easy data export
Export experiment data as spreadsheet files with a uniform time axis for further analysis and reporting.
Controlled mixing
Connect to our agitation systems to control and maintain adjustable mechanical agitation.
Read results from anywhere
Connect to your local network or the internet, so that you can monitor results from any device, including tablets and mobile phones.
Why choose BPC® Titan?
Easy to start up, easy to use
A simple, intuitive user interface makes setting up and monitoring any experiment easy. Just fill the instrument with water, connect to a power source, then start recording.
Accurate measurements in any environment
Utilising real-time temperature, pressure and humidity compensation ensures all gas volume and flow measurements are accurate across different environments
Operational flexibility
BPC® Titan is highly flexible for various applications. It can be operated as a stand-alone instrument for a specific application or combined with other technologies. BPC® Titan also enables running experiments in both batch and continuous modes of operations.
Structured data handling
Gas measurements, experiment settings and exported results are handled in one platform, reducing the need for separate files and manual calculations.
Pre-calibrated system
BPC® Go’s calibration-free flow cell units come in two resolutions (2 and 9 ml) and can be exchanged at any point.
Get a quote
within 48 hours
Request a quote from our sales team for gas flow and volume meters.
Aurora™ Software inlcuded
Aurora™ is the experiment software included with BPC® Titan. It is accessed through a web browser and gives users a clear way to set up tests, follow gas production, store data and export results without installing software on an external computer.
With local data storage and remote access, laboratories can follow long running anaerobic batch tests from the lab, office or another location.
- Experiment setup in the browser
- Real time gas production monitoring
- Local data storage on the instrument
- Data export for further analysis
- Remote access from computer, tablet or smartphone
Want to know more?
Need help choosing a gas flow and volume meter?
Tell us about your sample throughput, reactor volume and test type. We can help you identify the right configuration.
Technical Specifications
Measurement
Working principle
Liquid displacement and buoyancy
Measurement resolution
1.5 L
Detection capacity
10 million data points
Measuring range
0.1 to 360 L/h
Repeatability
CV ≤ 1%
Gases
Non-aggressive gases (e.g. CH4, CO2, H2, N2,…)
Technical
Built-in sensors
Temperature, Pressure, Hall, Gyro
Connections
Ethernet, Power supply, USB B, Motor control
Display
OLED 2.8”
256×64 white
Housing
Aluminium and plastic
Power supply
12 V DC / 1.0 A with 100-240 VAC
Usage
Indoor
Measurement medium
Deionised or distilled water
Operation temperature
0 – 50 °C
Operation pressure
-50 – 50 mbar
Dimensions
Unit dimensions
52 x 58 x 21 cm
Unit weight
20.3 kg
Power supply unit
89 x 48 x 33 mm, 127 g
Gas connector diameter
ID: 9 mm, OD: 13 mm
Recommended tube size
ID: 12 mm, OD: 16 mm
Downloads
Download product brochures and comparison documents.
Looking for manuals or other technical documentation?
You can find them in BPC Academy, our customer resource and training centre.
4 MB
Related products
-
BPC Titan
Recommended price
€9 000,00 -
Brushless DC Motor Kit for CSTR-5/10
Recommended price
€1 189,00 -
IC-20S
Recommended price
€8 260,00 -
UASB/EGSB-20S
Recommended price
€7 160,00
Common questions about BPC® Titan
What is BPC® Titan used for?
BPC® Titan is used for automated gas flow and volume measurements at low volumes (0.1 to 360 L/h)
Does BPC® Titan require an external computer?
No. BPC® Titan has an embedded server and local data storage. Aurora™ software is accessed through a web browser, so no software installation on an external computer is required.
Talk to an expert about BPC® Titan
Share your application, expected sample throughput and the type of gas measurement you need. Our product specialists can help you choose the right BPC® Titan configuration and suitable accessories for your laboratory.
